Motherboard |
Motherboard | Super C7Z87-OCE |
Processor/Cache |
CPU | Single Socket H3 (LGA 1150) |
| Intel® 4th Gen Core i7/i5/i3 processors |
System Memory |
Memory Capacity | 4x 240-pin DDR3 DIMM slots |
| Supports up to 32GB DDR3 Non-ECC Un-Buffered memory (UDIMM) |
Memory Type | 1600MHz non-ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
| Support overclocking up to 2133MHz* / 2200MHz* / 2400MHz* / 2600MHz* / 2800MHz* / 3000MHz* * Please check the operation manual for supported components |
DIMM Sizes | 8GB, 4GB, 2GB, 1GB |
Memory Voltage | 1.5V, 1.35V |
On-Board Devices |
Chipset | Intel® Z87 Chipset |
SATA | SATA3 via PCH w/ RAID 0, 1, 5, 10 |
| SATA3 via ASM1061® |
Network Controllers | Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output |
| Intel® i217V + Intel® i210AT Controllers |
Audio | RealTek ALC1150 High Definition Audio |
Input / Output |
SATA | 6x SATA3 (6Gbps) ports via PCH |
| 2x SATA3 (6Gbps) ports via ASM1061® |
| Total of 8x SATA3 ports (6Gbps) |
LAN | 2x RJ45 Gigabit Ethernet LAN ports |
USB | 6x USB 3.0 ports (2 front, 4 rear) |
| 4x USB 2.0 ports (2 front, 2 rear) |
Audio | 7.1 HD Audio by Realtek ALC1150 |
Display | 1x VGA, 1x HDMI, 1x DVI, 1x Thunderbolt (DP1.1), Triple display support |
Serial Port / Header | 1x COM port (header) |
Expansion Slots |
PCI-Express | 3 (x16) PCI-E 3.0 slots - Function as: 16/NA/NA or 8/8/NA or 8/4/4 |
| 3 (x1) PCI-E 2.0 in x4 slots |
System BIOS |
BIOS Type | 128Mb SPI Flash EEPROM with AMI® BIOS |
BIOS Features | ACPI 5.0 |
| USB Keyboard support |
| DMI (SMBIOS) 2.7 |
Chassis |
Form Factor | Mid-Tower |
Model | CSE-732G-903B |
Dimensions and Weight |
Height | 20.08" (510mm) |
Width | 8.66" (220mm) |
Depth | 22.83" (580mm) |
Gross Weight | 35 lbs (15.87 kg) |
Available Colors | Black |
Front Panel |
Buttons | Power On/Off button |
LEDs | Power LED |
| System Information LED |
| Hard drive activity LED |
| Network activity LED |
Ports | 2x front USB 3.0 Ports |
| 2x front USB 2.0 Ports |
| 1x front HD/AC97 Audio Port |
| 1x eSATA Port |
Drive Bays |
Hot-swap | 3x 3.5" Hot-swap Internal Drive Bays |
| 2x 3.5" Hot-swap External Drive Bays |
| Optional 4x 2.5" Hot-swap External Drive Bay Cage |
Peripheral | 2x 5.25" Peripheral Drive Bays |
| 1x 3.5" Device Bay |
System Cooling |
Fans | 1x 12cm rear exhaust fan |
| 1x 12cm front cooling fan |
Power Supply |
Power Supply | 900W AC multi output power supply |
AC Voltage | 100-240 V, 50-60 Hz, 10-6 Amp |
+5V Standby | 3 Amp |
+12V1 | 25 Amp |
+12V2 | 25 Amp |
+12V3 | 25 Amp |
+12V4 | 25 Amp |
+5V | 25 Amp |
+3.3V | 25 Amp |
-12V | 0.5 Amp |
Certification | Gold Level |
Note: | • Max. continuous combined load on +3.3V and +5V output shall not exceed 155W. • Max. continuous combined load on +12V1, +12V2, +12V3 and +12V4 output shall not exceed 860W. |
PC Health Monitoring |
CPU | 6-Phase-switching voltage regulator |
| Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory, Chipset Voltages. |
FAN | Low noise fan speed control |
Temperature | Monitoring for CPU and chassis environment |
| PECI |
| Thermal Control for 8x fan connectors |
Operating Environment / Compliance |
RoHS | RoHS Compliant |
Environmental Spec. | Operating Temperature: 10°C to 35°C (50°F to 95°F) |
| Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
| Operating Relative Humidity: 8% to 90% (non-condensing) |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Product SKUs |
Product SKUs | SYS-5038AD-T (Black) |
